SARITOR 62 Active

Type

Self propelled

Tank Capacity

6200 l

Boom Width

36 - 48.5 m

Boom Types

TERRA FORCE / PARAGON

SARITOR 62 Active

Type

Selfpropelled

Tank Capacity

6200 l

Boom Width

36 - 48.5 m

Boom Types

TERRA FORCE / PARAGON

In front of the field

SARITOR 62 Active takes a proven sprayer to the next level with a larger stainless steel  tank, more power, improved comfort and advanced booms.

This uniquely Australian SARITOR is driven by a 300HP Cummins QSB 6.7 litre diesel engine, driving four Danfoss Hydrostatic wheel motors. The Cat.4 cab provides a cool, clean operator environment with fingertip controls and your choice of ISOBUS controller.

And in the field, a range of steel or HARDI PARAGON aluminium booms from 36 m to 48.5 m eat up the acres with unrivalled ride and remarkably precise height management.

Unrivalled boom ride

One of the most outstanding features of SARITOR 62 Active is its remarkable boom ride. Capitalising on HARDI's 30+ years of experience, SARITOR uses a wide Paralift boom centre with HARDI's AutoTerrain boom height and stability control, coupled to patented  yaw dampening.

This intelligent, integrated system proactively positions the boom to proactively compensate for terrain changes.

The result is precise tip-to-tip height control, for more accurate spraying and near-zero chance of ground strikes, even with high spraying speeds and our widest aluminium booms.


ActiveAir nozzle control

The ActivAir nozzle on/off system uses SARITOR's onboard air supply to instantly open and close nozzles on demand, with no dripping.

Solenoids along the boom ensure precise switching for spraying and AutoSection control, with short air connections from each solenoid to its nozzle(s) for an instantaneous response.

Fluid recirculation maintains pressure in the boom, so nozzles spray at the correct rate from the moment they're activated, and provides simple boom flushing and rinsing without having to emtpy the rinse solution into the field


All for the operator

The new SARITOR is designed around the operator, with numerous features to make spraying safer, more precise, and less fatiguing.

A large, quiet, climate controlled, and pressurised Category 4 cab offers superb visibility to the front as well as back over the boom, while ISOBUS connectivity allows a wide choice of controllers.

Filling and cleaning is all managed from the single WorkZone, which includes FastFill connections and TurboFiller, as well as Ground Control Console for managing valves, pumps, rinsing and more.


Get the SARITOR brochure

See all the information about the SARITOR including full specifications, in-depth information and much more!

Download your SARITOR brochure

Specifications

Tank6200
Pump, l/minACE 650 run-dry centrifugal
Pump capacity, l/min60
Booms, mTR5 (Aluminium) 36.5, 38.5, 40.5, 42.5
Booms, mB3 MEGA (Aluminium) 48.5
Booms, mTERRA FORCE 36, 38, 40, 42
ControllerHC 9600
EngineCummins QSB 6.7 litre, 300 hp
Fuel tank capacity, l600
Transmission4WD Sauer, Danfoss hydrostatic
SuspensionAirbag + shock aborbers
Steering2-wheel steering
Track width, m3.00 to 3.50 (hydraulic adjust.)
Turning circle (curb to curb), m20.5 (radius 10.25)
Transport speed, km/h55
Weight (empty), kg14,500 (42 m boom)
Total length, m9.50
Total transport height, m3.97
Width (TERRA FORCE), m4.20 (transport 3.50)
Track width (480/80 R50), m3.00 to 3.50
Wheel base, m4.26
Clearance (480/80 R50), m1.45
Rinse Tank, l450
Hand wash tank, l30
Storage locker, l500
Tyres (standard)480/80 R50
Tyre options380/105 R50
520/85 R46
620/70 R42"





Show full specifications
